Nizar Sheetsandplates, located in Amman, Jordan, stands out as a top manufacturer and supplier of premium metals, with a special focus on Monel products. Their Monel 400 Foils are celebrated for their durability, precision, and remarkable resistance to corrosion. Crafted using cutting-edge manufacturing techniques and rigorous quality control, these foils adhere to the highest industrial standards. Catering to sectors like marine engineering, chemical processing, aerospace, and oil and gas, Nizar Sheetsandplates guarantees that each Monel 400 Foil provides consistent performance, long-lasting reliability, and structural integrity, making them perfect for applications that demand strength and resilience in tough environments.
Monel 400 Foil is mainly made up of nickel (63–70%) and copper (28–34%), along with trace amounts of iron and manganese. This unique blend offers exceptional resistance to corrosion, especially against seawater, acids, and alkalis. On the mechanical side, Monel 400 Foils boast impressive tensile strength, toughness, and ductility, which allows for easy fabrication without sacrificing performance. They are non-magnetic and stable across a wide temperature range, merging strength with chemical stability, making them ideal for challenging industrial applications where durability and corrosion resistance are essential.
| Standards | ASTM B127 / ASME SB127 |
| Thickness | 0.3 – 10.0mm & AS PER CUSTOMER’S REQUIREMENT |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm & AS PER CUSTOMER’S REQUIREMENT. |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm & AS PER CUSTOMER’S REQUIREMENT. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard AS PER CUSTOMER’S REQUIREMENT. |
| Test Certificate | Chemical test, Fitting test, Alloy test, Radiography test, Macro and micro-test, Hydrostatic test, Impact test. |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled (HR), Cold rolled (CR), SATIN (Met with Plastic Coated) etc. |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
Monel DIN 2.4360 Foils offer outstanding advantages, including excellent corrosion resistance in seawater, acidic, and alkaline environments, making them ideal for marine and chemical applications. They possess high mechanical strength and durability, ensuring long-lasting performance under extreme conditions. Monel 400 foils maintain stability across a wide temperature range, providing reliable functionality in high-temperature settings. Their excellent resistance to stress corrosion cracking and pitting enhances their dependability in critical applications. Easy to fabricate and weld, these foils are versatile for use in diverse industries, including aerospace, marine, chemical processing, and electrical systems.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
Monel 400 Foils find extensive use in industries that demand materials with high strength and corrosion resistance. In marine settings, they are utilized for shipbuilding, seawater-handling equipment, and fasteners. In the realm of chemical processing, they are employed in heat exchangers, pipelines, and reaction vessels that come into contact with corrosive substances. The aerospace and oil and gas sectors rely on Monel 400 Foils for structural components and critical high-stress applications. Their blend of corrosion resistance, mechanical strength, and dependability makes Monel 400 Foils a top choice for industrial, marine, and chemical applications.
