Operating from the industrial heart of Amman, Jordan, Nizar Sheetsandplates is your trusted partner for high-performance alloys, specializing in the supply of premium Hastelloy B3 sheets and plates. We understand that in demanding industrial environments, the integrity of your materials is non-negotiable. That’s why we are dedicated to providing robust and reliable solutions that are built to withstand the most aggressive conditions, ensuring your projects benefit from superior quality and lasting durability right from the start. Our focus is on delivering materials you can count on.
Hastelloy B3 is engineered with a specific nickel-molybdenum composition that grants it exceptional stability and resistance to hydrochloric acid at various concentrations and temperatures. This advanced alloy also offers superior protection against other non-oxidizing acids, making it far less prone to embrittlement than earlier versions. Its impressive mechanical strength and ductility are maintained even after prolonged exposure to high heat, ensuring structural integrity in harsh chemical processing environments where other materials might quickly fail.
Specifications :ASTM B333 / ASME SB333
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 4000mm, etc
Thickness : 0.3 mm to 120 mm
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form : Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange)
| Grade | C | Mn | Si | Al | Co | Ni | Cr | Fe | Mo | Ti |
| Hastelloy B3 | 0.01 max | 3.0 max | 0.10 max | 0.50 max | 3.0 max | 65.0 min | 1.5 | 1.5 | 28.5 | 0.2 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 9.22 g/cm3 | 1418°C (2585°F) | 1000 – 2000 N/mm² , 145 – 290 ksi | 62 – 183 Ksi, 425 – 1260 MPa | 57 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Hastelloy B3 | 2.4600 | N10675 |
Stocked Sizes | |
|---|---|
Size (in inches) | Size (in mm) |
.125″ | 3.18mm |
.134″ | 3.40mm |
.156″ | 3.96mm |
.187″ | 4.75mm |
.250″ | 6.35mm |
.312″ | 7.92mm |
.375″ | 9.53mm |
.500″ | 12.7mm |
.600″ | 15.9mm |
.750″ | 19.1mm |
.875″ | 22.2mm |
1″ | 25.4mm |
1.125″ | 28.6mm |
1.250″ | 31.8mm |
1.500″ | 38.1mm |
1.750″ | 44.5mm |
2″ | 50.8mm |
2.500″ | 63.5mm |
3″ | 76.2mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hastelloy B3 sheets and plates offer exceptional advantages, especially in harsh, corrosive environments. They provide outstanding resistance to hydrochloric acid, sulfuric acid, and other aggressive chemicals ensuring reliability in chemical processing and waste treatment applications. With excellent resistance to pitting, crevice corrosion, and stress corrosion cracking they ensure long-term durability. The materials high strength and ease of fabrication further enhance its suitability for complex designs and welding. Hastelloy B3 superior performance in reducing conditions, combined with its ability to maintain structural integrity under extreme conditions, makes it a preferred choice for critical industrial applications.
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
The exceptional corrosion resistance of Hastelloy B3 sheets makes them an indispensable choice for the chemical processing industry. You will find them expertly fabricated into critical components like reactors, heat exchangers, and piping systems that handle hydrochloric acid. They are also vital in pickling operations, acid production plants, and pharmaceutical manufacturing, wherever severe chemical environments are the norm. Choosing this material is a strategic decision for long-term equipment reliability, significantly reducing maintenance needs and extending the operational life of your most demanding assets.
