Stainless Steel 304L Sheets and Plates are top-notch austenitic stainless steel products crafted by Nizar Sheetsandplates in Amman, Jordan. They’re celebrated for their outstanding corrosion resistance, durability, and versatility. The low-carbon “L” grade helps prevent carbide precipitation during welding, which means they perform reliably in both corrosive and high-temperature settings. These sheets and plates are meticulously processed to ensure smooth surfaces, consistent thickness, and excellent dimensional accuracy. Various industries in Jordan count on SS 304L Sheets and Plates for construction, chemical processing, food and beverage, and general engineering applications, where dependable corrosion resistance, mechanical strength, and structural stability are crucial.
Stainless Steel 304L Sheets and Plates are made up of 18–20% chromium and 8–12% nickel, with a carbon content of ≤0.03% to boost corrosion resistance and weldability. They showcase impressive tensile strength, toughness, and ductility, making them easy to form and resistant to impact. Thanks to their austenitic structure, they stand strong against rust, oxidation, and chemical attacks in various environments. SS 304L also maintains its shape under mechanical stress and thermal cycling. These mechanical and chemical properties make it a go-to choice for industrial, architectural, and high-performance engineering applications where durability and reliability are key.
| Standard | ASTM A240, ASME SA240 |
| Thickness | 0.1mm to 12 mm Thk |
| Sheet/Plate Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sandblast, Brush, etching. |
| Finish | Hot rolled (HR), Cold rolled (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated), Galvanized etc. |
| Grade | C | Ni | Si | N | S | Mn | P | Cr | Mo | |
| SS 304L | min. | – | 8.0 | – | – | – | – | – | 18.0 | – |
| max. | 0.030 | 12.0 | 0.75 | 0.10 | 0.030 | 2.0 | 0.045 | 20.0 | ||
| Grade | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| SS 304L | 485 | 40 | 170 | 92 | 201 |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| SS 304L | S30403 | 1.4306/1.4307 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 | SUS 304L | 304S11 | 03Х18Н11 |
Grade | Density of ss304 in kg/m3 | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Thermal Conductivity (W/m.K) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (nΩ.m) | |||
0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
304L | 8000 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 500 | 720 |
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 304L sheets and plates offer many advantages, including excellent corrosion resistance, especially in harsh environments such as chemical and coastal environments where 304L’s low carbon content increases and reduces its weldability risk of carbide precipitation, making it ideal for welding applications. It is very durable, stain resistant and requires little maintenance. 304L also has excellent strength and toughness at high and low temperatures. Its versatility makes it suitable for a wide range of industries, including food processing, pharmaceutical manufacturing and manufacturing.
Stainless Steel 304L Sheets and Plates find their way into many industries that need materials that are corrosion-resistant, durable, and versatile. They’re perfect for chemical processing equipment, storage tanks, pressure vessels, piping systems, and heat exchangers. In the realms of construction and architecture, they’re used for cladding, roofing, decorative panels, and structural supports. The food, beverage, and pharmaceutical sectors rely on 304L Sheets and Plates for hygienic applications, including countertops and equipment, ensuring safety and cleanliness in their operations.
