Nizar Sheetsandplates, located in Amman, Jordan, stands out as a top manufacturer and supplier of premium stainless steel products, with a focus on Stainless Steel 316H Sheets and Plates. Known for their unwavering dedication to quality, Nizar Sheetsandplates provides robust, corrosion-resistant, and precisely engineered steel solutions that cater to a variety of industries. Thanks to their cutting-edge manufacturing facilities and rigorous quality control processes, the company guarantees that every sheet and plate adheres to international standards. Their deep knowledge of metallurgy and ability to customize products means clients can expect tailored solutions for even the most demanding environments, making Nizar Sheetsandplates a reliable partner for projects that require exceptional performance and dependability.
Stainless Steel 316H Sheets and Plates are primarily made up of iron, chromium (16–18%), nickel (10–14%), and molybdenum (2–3%), which significantly boosts their corrosion resistance and high-temperature strength. The “H” designation signifies a higher carbon content, enhancing creep resistance at elevated temperatures. On a mechanical level, 316H boasts impressive tensile strength, yield strength, and hardness, all while maintaining good ductility and toughness. It can handle temperatures up to 870°C in continuous service, making it perfect for high-stress applications. This combination of features ensures longevity, durability, and stability under thermal and chemical stresses, making 316H an excellent choice for tough industrial settings.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316H | 0.10 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16 – 18 | 2 – 3 | 10 – 14 | 68.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 316H | 1.4401 | S31609 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
You’ll find Stainless Steel 316H Sheets and Plates commonly used in chemical and petrochemical plants, power generation facilities, marine environments, and food processing industries, thanks to their outstanding corrosion resistance and high-temperature stability. They’re perfect for heat exchangers, pressure vessels, boilers, and storage tanks, where strength and durability are essential. Plus, their resistance to pitting, crevice corrosion, and oxidation makes them ideal for marine equipment, desalination plants, and offshore applications. With their ease of fabrication and excellent weldability, these sheets and plates are a go-to choice for many demanding applications.
Stainless steel 316H sheets and plates are widely used in hot humid environments, due to their high strength and oxidation resistance Typical applications include chemical reagents, heat exchangers, pressure vessels and reactors in the petrochemical industry. It is used in marine environments, offshore structures and power plants, where chloride preservatives are needed. Additionally, 316H is used in food and pharmaceutical applications due to its purity properties. Its durability and high-temperature performance make it ideal for applications involving extreme temperatures and corrosion.
