Nizar Sheetsandplates, a well-respected manufacturer and supplier based in Amman, Jordan, specializes in high-quality Stainless Steel 317L Sheets and Plates. These products are specifically crafted for applications that demand outstanding corrosion resistance and durability. The low-carbon variant of 317 stainless steel excels in environments rich in chlorides and acids, making it a top choice for industries that require long-lasting reliability. Nizar Sheetsandplates guarantees precision rolling, a flawless surface finish, and consistent mechanical strength in every sheet and plate. With cutting-edge production capabilities and rigorous quality control, the company provides SS 317L products that adhere to international standards, supporting high-performance needs in industrial, chemical, and marine sectors.
Stainless Steel 317L Sheets and Plates are composed of 18–20% chromium, 11–15% nickel, and 3–4% molybdenum, featuring a lower carbon content that enhances both weldability and resistance to sensitization. This alloy boasts impressive mechanical properties, including high tensile strength, good yield strength, and robust resistance to pitting and crevice corrosion in harsh chemical environments. Its low-carbon makeup prevents carbide precipitation during welding, ensuring structural integrity. Additionally, SS 317L maintains excellent toughness, formability, and stability at elevated temperatures, making it perfect for demanding industrial applications where both corrosion and heat resistance are crucial.
| 317L Sheets & Plates Specifications | ASTM A240 / ASME SA240, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| 317L Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| SS 317L Sheets & Plates Size Range | Cold rolled ASME SA240 Grade 317L Stainless Steel Sheet 0.5-6.4 mm Hot rolled ASME SA240 Grade 317L Stainless Steel Sheet 3.0–10.0 mm |
| 317L SS Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| SS 317L Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| SS 317L Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Stainless Steel 317L Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Stainless Steel 317L Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SA240 317L SS Strips EN 10088 SA -240-304 / 317L Strips |
| Finish of SS 317L Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 317L | 1.4438 | S31703 | SUS 317L | X2CrNiMo18-15-4 |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
| 2000MM X 1000MM X 3MM | 2000MM X 1000MM X 6MM |
| 2500MM X 1250MM X 4MM | 2500MM X 1250MM X 8MM |
| 3000MM X 1500MM X 3MM | 3000MM X 1500MM X 6MM |
| 3000MM X 1500MM X 4MM | 3000MM X 1500MM X 8MM |
| 2000MM X 1000MM X 5MM | 2500MM X 1250MM X 10MM |
| 2500MM X 1250MM X 3MM | 2500MM X 1250MM X 6MM |
| 4000MM X 2000MM X 3MM | 4000MM X 2000MM X 6MM |
| 2500MM X 1250MM X 5MM | 3000MM X 1500MM X 10MM |
| 2000MM X 1000MM X 4MM | 2000MM X 1000MM X 8MM |
| 4000MM X 2000MM X 4MM | 2000MM X 2000MM X 10MM |
| 3000MM X 1500MM X 5MM |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 317L sheets and plates offer many advantages, including exceptional corrosion resistance, especially in high chloride environments Their low carbon content increases weldability, prevents carbide precipitation and provides good welding strength after the. They exhibit excellent resistance to pitting, crevice corrosion, and stress corrosion cracking, making them ideal for chemically complex marine environments 317L also maintains excellent tensile strength, rigidity and formability at temperature in a higher order. These properties make them ideal for use in industries such as the chemical industry, pharmaceutical manufacturing, marine and food processing, where durability and reliability are essential.
Stainless Steel 317L Sheets and Plates find extensive use in industries that require remarkable corrosion resistance and strength. They are particularly suited for chemical processing equipment, pulp and paper machinery, marine components, and food processing systems that are exposed to acidic or chloride environments. The alloy’s exceptional resistance to pitting and crevice corrosion makes it ideal for heat exchangers, evaporators, condensers, and pharmaceutical processing units. SS 317L is also utilized in pet food processing, ensuring that it meets the rigorous demands of various applications.
