If you’re looking for top-notch Stainless Steel 316Ti Sheets and Plates, Nizar Sheetsandplates in Amman, Jordan has got you covered. These products are crafted to provide outstanding corrosion resistance, heat stability, and long-lasting durability, making them perfect for tough industrial applications. Thanks to the addition of titanium, SS 316Ti not only resists sensitization but also keeps its strength even in high-temperature settings. Nizar Sheetsandplates takes pride in delivering sheets and plates with precise thickness, a smooth surface finish, and consistent quality through cutting-edge manufacturing techniques. This makes them an excellent choice for chemical plants, marine environments, heat exchangers, and engineering projects that demand reliable, high-performance stainless steel materials.
Stainless Steel 316Ti is an austenitic grade that includes chromium, nickel, molybdenum, and titanium for stabilization. This unique blend boosts its resistance to intergranular corrosion and enhances its strength at high temperatures. With impressive mechanical properties like excellent tensile and yield strength, good ductility, and remarkable resistance to pitting and crevice corrosion in chloride-rich settings, this alloy is a solid choice. It maintains structural integrity during welding and thermal exposure, ensuring it performs well over time. Plus, SS 316Ti is known for its reliable formability and weldability, making it suitable for a variety of fabrication and processing tasks.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316Ti | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.395 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316Ti | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
These Stainless Steel 316Ti Sheets and Plates are widely utilized in industries where exceptional corrosion resistance and thermal stability are essential. They’re perfect for heat exchangers, condenser tubes, chemical processing equipment, pharmaceutical machinery, and petrochemical systems. In marine applications, they excel in saltwater and moisture-heavy environments. You’ll also find these sheets and plates in food processing, architectural structures, pressure vessels, and various industrial fabrication projects. Their ability to endure high temperatures and corrosive substances guarantees dependable performance, less maintenance, and a long service life across a range of industrial and commercial applications.
Stainless steel 316Ti sheets and plates are widely used in applications requiring excellent corrosion resistance and high temperature stability. They are ideal for medical devices, heat exchangers and pressure vessels due to their resistance to intergranular corrosion and scaling and are used for boat equipment and desalination plants in marine environments. Their strength and power make them suitable for building materials, ventilation systems and exhaust systems. In addition, they are used in medical devices, food processors, and construction materials for their hygienic and aesthetic properties.
